Install OS Raspberry Pi 2TB SSD NVMe M.2 M-Key PCIe Gen3x4 Form Factor 2280

##################################
READY STOCK, SILAHKAN LANGSUNG ORDER
##################################

INSTALL OS RASPBERRY pada SSD NVME

----------------------------
Username : pi
Password : raspberry
----------------------------

Capacity : 2TB SSD NVMe M.2 PCIe Gen3x4
Form Factor : 2280

Compatibility : NVME M.2 HAT/Board Raspberry Pi 5

Hasil pengetesan aktual DIRECT TEST pada device Raspberry Pi 5 :
Disk READ Speed : ±784 MB/s (= 6272 Mbps)
Disk WRITE Speed : ±427 MB/s (= 3416 Mbps)
(Silahkan geser gambar ke-2)

Note :
Sekitar 7% dari kapasitas digunakan untuk keperluan sistem internal SSD nya sendiri, sehingga AVAILABLE capacity nya ada dibawahnya.

Useable Size : ±1.8TB
OS Partition : ±371.6GB
----bootfs : ±512MB
----rootfs : ±371.1GB
DATA Partition : ±1.5TB (Folder SHARED, can be accessed from LAN Network)

Jadi dengan NVME ini, unit raspberry nya juga akan sekaligus bisa difungsikan sebagai NAS (Network Attached Storage) pada DATA partition nya.

*** Free Baut/Screw ***

---

SPECIFICATION :

Brand : Billion Reservoir
Model name : J20
Form factor : M.2 2280
Dimensions : 80.0(L) x 22.0(W) x 3.7(H) mm
NAND Flash : 3D QLC
TLC Capacity : 128GB/256GB/512GB/1TB/2TB
Interface : M.2 M Key, PCIe Gen3x4 with NVMe
Input Voltage : DC +3.3V
Operation Temperature : 0°C ~ 70°C
Storage Temperature : -40˚C ~ 85˚C
Warranty : Limited 3-year
Weight : 11g
IOPS : Random Read/Write 180K/140K IOPS Max[3]
Humidity : 0°C ~ 55°C / 5% ~ 95% RH, non-condensing
Vibration : RH 90% under 40°C (operational)
Shock : 1,500G/0.5ms
MTBF : 3,000,000 hours
Operating System :
--- Windows 10 / 8.1 / 8 / 7
--- MAC OS 10.4 or later
--- Linux 2.6.33 or later
--- Others

---
